- Magnification Low: 1
- Magnification High: 8
- Objective diameter: 24
- Maintube diameter: 30
- Eyepiece Field of view: 20
- Diopter range +/-: 2
- Exit Pupil Distance (mm): 96
- Est. yearly qty: 100
- Parallax Compensation: 100yds
- Fast focus eyepiece: yes
- Sealing gas used: Nitrogen
- Clear aperture min magnification (mm): 10
- Clear aperture max magnification (mm): 24
- Eff. exit pupil diameter @ min. magnification ± 3 %: 10.0
- Eff. exit pupil diameter @ max. magnification ± 3 %: 3.0
- Maximum resolution in Arc. Second (min. Magnification): 17
- Maximum resolution in Arc. Second (max. Magnification): 7
- Range of Function temperature (Unit can still be operated): -25°C/+55°C
- Storage temperature: -40C to +85C
- objective field of view @ min magnification (ft @100yds): 109.2
- objective field of view @ max magnification (ft@100yds): 13.6
